Сервер Supermicro SuperServer NVMe SYS-1028U-TNRTP+
2x Intel® Xeon E5-2600, 24 DIMM DDR, 10 SATA3 (6 Gbps) + 8x SAS3 + 2x NVMe, Complete System Only, 750W
Цена по запросу
Поделиться страницей:
Список компонентов в комплекте сервера 1028U-TNRTP+ (Complete System Only)
| Тип | Партномер | Кол-во | Описание |
| Материнская плата / Шасси |
MBD-X10DRU-i+ CSE-119UAC2-R751-T |
1 1 |
Super X10DRU-i+ Motherboard CSE-119UAC2-R751-T Chassis |
| Воздушный кожух | MCP-310-81903-0B | 1 | Mylar air shroud set for SC819U,119U (X10DRU+),HF |
| Дополнительная карта / модуль | AOC-URN2-I2XS | 1 | 1U Ultra Riser based on Intel 82599ES controller with 2 10Gb SFP+ ports, 2 NVMe ports, and 1 internal PCI-E x8 3.0 slot |
|
Backplane |
BPN-SAS3-116A-N2 | 1 | 10-port 1U SAS3 12Gbps Hybrid backplane, support up to 8x 2.5-inch SAS3/SATA3 HDD/SSD and 2x SAS3/SATA3/NVMe Storage Devices |
|
Кабель 1 |
CBL-SAST-0655 | 1 | MINI SAS HD(ST)-MINI SAS(RA-RS EXIT),6G,INT,47CM,SB,30AWG |
| Кабель 2 | CBL-SAST-0658 | 2 | MINI SAS HD,INT,PCIe NVMe SSD, 60CM,30AWG |
| Кабель 3 | CBL-PWEX-0653 | 1 | 8 pin female to 4 pin female power, 37cm, 18AWG,RoHS/REACH |
| Кабель 4 | CBL-0484L | 2 | SATA,INT,ROUND,ST-ST,55CM,30AWG |
| Кабель 5 | CBL-CDAT-0662 | 1 | CBL,SGPIO,2X4F TO 2X4F,P2.54,ROUND CABLE,61.5CM,28AWG |
| Кабель 6 | CBL-PWEX-0650 | 1 | 8 pin female to 2x RA(Right Angle) big 4 pin female power, 47/62CM, 18AWG,RoHS/REACH |
| Кабель 7 | CBL-SAST-0656 | 1 | MINI SAS HD(ST)-MINI SAS(RA-RS EXIT),6G,INT,39CM,SB,30AWG |
| Отсеки для накопителей |
MCP-220-00127-0B MCP-240-81910-0N |
2 1 |
Black gen-3 2.5 NVMe drive tray, Orange tab with lock (for hotswap NVMe drive),HF,RoHS/REACH Rear window for SC819U, 119U tool-less chassis (i2XS) |
| Маркировка | LBL-0108 | 1 | CAUTION LABEL FOR REDUNDANT PWR SYSTEMS |
| Руководство по эксплуатации | MNL-1678-QRG | 1 | SYS-1028U-TR(4/4T/T/TP)+, QRG,HF,RoHS/REACH |
| Части | MCP-150-00009-0B |
1 |
Internal AOC rubber support for SC819U, 119U |
|
Райзер-карта |
RSC-R1UW-2E16 RSC-R1UW-E8R |
1 1 |
1U LHS WIO Riser card with two PCI-E x16 slots 1U RHS WIO Riser card with one PCI-E x8 slot |
|
Радиатор |
SNK-P0047PS |
2 |
1U Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Narrow ILM MB |
| Блок питания | PWS-751P-1R | 2 | 1U 750W Redundant Platinum Single Output Power Supply w/Pmbus W73.5xH40xL203mm,RoHS/REACH |
| Вентиляторы | FAN-0101L4 | 5 | 40x40x56 mm, 14.4K-10.7K RPM Counter-rotating Cooling Fan |
| Комплект рельсов |
MCP-290-00102-0N MCP-290-00120-0N MCP-290-00112-0N |
1 1 1 |
Outer rail, quick-release type, 25.6" to 33.05" Inner rail, front, quick-release type (thumb screw applied) Inner rail, extension, long (quick) for 1U 17.2"W chassis |
Список опциональных компонентов для сервера 1028U-TNRTP+ (Complete System Only)
| Тип | Партномер | Кол-во | Описание |
| Комплект рельсов |
MCP-290-00062-0N MCP-290-00064-0N MCP-290-00052-0N-BULK |
- - - |
Inner/outer rail set, quick-release type, 25.6" to 33.05" Thumb screw adapter of inner rail for 1U 17.2" Bulk outer rail, quick-release type, 25.6" to 33.05" (10 sets/pack) |
| 10GbE SFP+ Direct Attach Cable (DAC, copper wire) |
CBL-0347L CBL-0348L CBL-0349L CBL-NTWK-0347 CBL-NTWK-0456 |
- - - - - |
1M 10G SFP+ to SFP+ Passive Copper M-M Pull type 30AWG 3M 10G SFP+ to SFP+ Passive Copper M-M Pull type 24AWG 5M 10G SFP+ to SFP+ Passive Copper M-M Pull type 24AWG 1M 10G SFP+ to SFP+ Passive Copper M-M Push type 30AWG 2M 10G SFP+ to SFP+ Passive Copper M-M Push type 30AWG |
| Карты и кабели контроллера памяти |
AOC-S3008L-L8e & 2x CBL-SAST-0593 AOC-S3008L-L8i & 2x CBL-SAST-0593 AOC-S3108L-H8iR & 2x CBL-SAST-0593 |
- |
Std LP, 8 internal ports, 12Gb/s per port- Gen3, 122HDD, HBA; Internal Mini-SAS HD to Mini-SAS HD 60cm,30AWG,12Gb/s Std LP, 8 internal ports, 12Gb/s per port- Gen3, 63HDD, RAID 0,1,1E; Internal Mini-SAS HD to Mini-SAS HD 60cm,30AWG,12Gb/s Std LP, 8 internal ports, 12Gb/s per port- Gen3, 240HDD, RAID 0, 1, 5, 6, 10, 50, 60; Internal Mini-SAS HD to Mini-SAS HD 60cm,30AWG,12Gb/s |
| Сетевые карты |
AOC-SGP-i2/4 AOC-STGN-i1S/i2S AOC-STG-b4S AOC-STG-i2T AOC-STG-i2 AOC-S40G-i2Q More |
- - - - - - - |
Standard LP, 2/4x GbE RJ45, PCI-E x4, Intel i350 Standard LP, 1/2x 10GbE SFP+, PCI-E x8, Intel 82599EN Standard LP, 4x 10GbE SFP+, PCI-E x8, Broadcom BCM57840S Standard LP, 2x 10GbE RJ45, PCI-E x8, Intel X540 Standard LP, 2x 10GbE CX4, PCI-E x8, Intel 82598EB Standard LP 2-port 40GbE controller, based on Intel Fortville XL710 AOC Compatibility Matrix |
| Хранилище кеша |
BTR-CV3108-1U1 BTR-TFM8G-LSICVM02 & BKT-BBU-BRACKET-05 |
- - |
CacheVault for Broadcom 3108 with Supercap mounting in 1U 40x56 fan tray CacheVault for Broadcom 3108; Supercap mounting bracket for PCI-E location |
| Вентиляторы | FAN-0101L4 |
До 3 |
40x40x56 mm, 14.4K-10.7K RPM Counter-rotating Cooling Fan |
| 1U Кабель | MCP-290-00152-0N |
1 |
1U Supermicro Cable Management Arm 2nd Gen |
| Услуги и поддержка |
OS4HR3/2/1 OSNBD3/2/1 |
- - |
3/2/1-year onsite 24x7x4 service 3/2/1-year onsite NBD service |
| ПО |
SFT-OOB-LIC SFT-DCMS-Single |
1 1 |
OOB Management Package (per node license) DataCenter Management Package (per node license) |
Характеристики сервера 1028U-TNRTP+ (Complete System Only)
| Форм-фактор |
1U стойка |
| Процессор |
2 процессора Intel® Xeon E5-2600, до 22 ядер на сервер |
| Память |
24 планки DIMM, До 3 Тб DDR4-2400MHz |
| Жесткие диски | До 10 Hot-swap 2.5" SAS/SATA HDD |
| Слоты расширения |
2x PCI-E 3.0 x16 slots (FH, 10.5" L), 2x PCI-E 3.0 x8 slots (LP, 1 internal) |
| Сетевые порты | 2x 10G SFP+ ports |
| Интерфейсы | 10x SATA3 (6Gbps), 8x SAS3 ports, 2x NVMe, 2x 10G SFP+ ports, 1x RJ45 Dedicated IPMI LAN port, 1x VGA, 2x USB 3.0 (спереди), 2x USB 3.0 (сзади), 1x USB 3.0 (Type A) |
| Блок питания | 750 Вт с резервированием |
| Размер, глубина | 1U, 724 мм |
